MCPClevis and Yoke Ends · Female
MTCA-16L
MTCA-16L, Clevis and Yoke Ends, Female M16 x 2.00 RH 16mm Pin Holes 16 x 64 Housing Aluminum
Drawings, photos & CAD downloads
Public previews are available above. A free account is required to download original files.
$18.27 per piece at 1+ quantity
Choose quantity / request quoteConfirm lead time and availability when requesting a quote.
Specifications
| Thread | M16 x 2 RH |
|---|---|
| Material | Aluminum |
Values without units follow the drawing.
Volume list pricing
USD per piece. Volume and dealer pricing are confirmed on quote.
| Quantity | Price per piece |
|---|---|
| 1+ | $18.27 |
| 2+ | $14.48 |
| 3+ | $13.65 |
| 4+ | $11.62 |
| 5+ | $10.07 |
| 10+ | $8.77 |
| 25+ | $6.53 |
| 50+ | $5.79 |
| 100+ | $5.41 |
| 250+ | $4.55 |
Drawing dimensions
| Threads | M16 x 2.00 RH |
|---|---|
| A | 96 |
| B | 26 |
| D | 64 |
| E | 16 |
| F | 32 |
| G | 16 |
| H | 115 |
| I | 32 |
| Material | Aluminum |
Lettered dimensions refer to the drawing for this part.
Product information
Construction: dimensions per DIN 71752.
Material: aluminum
WARNING: Cancer and Reproductive Harm. www.P65Warnings.ca.gov
